Mcbrimar

EHAUS EURO, PASSIVE HOUSE CLASSIC

Oamaru

Carbon Savings

6,900 KG

Heat Savings

91%

This captivating home offers three bedrooms, including a spacious master bedroom with an ensuite and walk-in robe. With a total area of 177 square meters, every area has been thoughtfully designed for optimal use. This project stands as a testament to the unwavering dedication of its owners. They embarked on a remarkable journey of exploration into the world of passive houses, investing hours in research until they found eHaus. Their vision was a certified passive house in Oamaru, and their unwavering determination paid off.

This home meets the eHaus Euro performance standard, delivering 91% predicted heat energy savings and is the first certified Passive House in Waitaki. This home is equipped with incredible features such as a Stiebel Eltron hot water heat pump that provides energy-efficient hot water, while a Zehnder Ventilation Unit guarantees clean, fresh air circulation throughout the house. The triple-glazed high-performance glass, a fully insulated concrete pad and 140mm timber framing allow for exceptional insulation, delivering year-round comfort and energy savings. Credit: Petra Hajnal, Designer.

"

Winter was so different from what we’re used to, not having to worry about the cold or condensation on the inside of the windows. It’s really quiet, warm, and no breeze, and when we get home in the evening it is really refreshing to walk into the house and it be just the right temperature without us turning anything on.

"

— Sam & Ashleigh

Design Components

Floor
Fully insulated concrete pad with a U-value of 0.169 W/(m²K)
Wall
140mm timber frame U-value of 0.222 W/(m²K)
Roof
Double layer of fibreglass insulation with a U-value of 0.129 W/(m²K)
Glazing
Triple Glazed Argon Ug value=0.52 W/(m²K) g- value =50%
Ventilation
Zehnder ComfoAir Q350 MHRV

Performance Specs

Heating Demand
20.9 kWh/(m²yr)
Heating Load
10W/m²
Frequency of Overheating
0%
Form Factor
3.65
Air Leakage @ 50Pa
0.6 ACH
Per Demand
53 kWh/(m²yr)

Consultant: Maria Rei

Certifier: Sustainable Engineering - Sara Wareing
